#include <tgUtil.h>

Static Public Member Functions
static btVector3	upVector ()

static std::string	degSymbol ()

static btVector3	center (const btVector3 &start, const btVector3 &end)

static btTransform	getTransform (const btVector3 &startOrientation, const btVector3 &start, const btVector3 &end)

static btTransform	getTransform (const btVector3 &start, const btVector3 &end)

static btTransform	getTransform (const btVector3 &center)

static btVector3	getVector (const btVector3 &from, const btVector3 &to)

static btVector3	getRadiusVector (btVector3 axis, double radius, btVector3 target)

static bool	almostEqual (const btVector3 &from, const btVector3 &to, int precision=5)

static btQuaternion	getQuaternionBetween (btVector3 a, btVector3 b)

static btVector3	getArbitraryNonParallelVector (btVector3 v)

static void	addRotation (btVector3 &v, const btVector3 &fixedPoint, const btVector3 &axis, double angle)

static void	addRotation (btVector3 &v, const btVector3 &fixedPoint, const btVector3 &fromOrientation, const btVector3 &toOrientation)

static void	addRotation (btVector3 &v, const btVector3 &fixedPoint, const btQuaternion &rotation)

static double	rad2deg (double radians)

static double	deg2rad (double degrees)

static std::string	strDeg (double degrees)

static double	round (double d, int precision=5)

Detailed Description

Contains only static constants and static member functions deemed generally useful.

Definition at line 46 of file tgUtil.h.

Member Function Documentation

static void tgUtil::addRotation	(	btVector3 &	v,
		const btVector3 &	fixedPoint,
		const btVector3 &	axis,
		double	angle
	)

inlinestatic

Rotate the provided vector (v) around a fixed point

Definition at line 252 of file tgUtil.h.

Here is the caller graph for this function:

static void tgUtil::addRotation	(	btVector3 &	v,
		const btVector3 &	fixedPoint,
		const btVector3 &	fromOrientation,
		const btVector3 &	toOrientation
	)

inlinestatic

Rotate the provided vector (v) around a fixed point

Definition at line 272 of file tgUtil.h.

Here is the call graph for this function:

static void tgUtil::addRotation	(	btVector3 &	v,
		const btVector3 &	fixedPoint,
		const btQuaternion &	rotation
	)

inlinestatic

Rotate the provided vector (v) around a fixed point

Definition at line 284 of file tgUtil.h.

Here is the call graph for this function:

static bool tgUtil::almostEqual	(	const btVector3 &	from,
		const btVector3 &	to,
		int	precision = `5`
	)

inlinestatic

Check that two vectors are almost equal within a given precision (default is 5 decimal places).

Parameters

[in]	from	a btVector3
[in]	to	a btVector3
[in]	precision	the number of decimal places; defaults to 5 if not supplied or negative

Definition at line 180 of file tgUtil.h.

Here is the caller graph for this function:

static btVector3 tgUtil::center	(	const btVector3 &	start,
		const btVector3 &	end
	)

inlinestatic

Return a btVector3 halfway between start and end.

Parameters

[in]	start	a btVector3
[in]	end	a btVector3

Returns: a btVector3 halfway between start and end

Definition at line 74 of file tgUtil.h.

Here is the caller graph for this function:

static double tgUtil::deg2rad ( double degrees )

inlinestatic

Convert degrees to radians.

Parameters

[in] degrees an angle measured in degrees

Returns: the angle as measured in radians

Todo:: Normalize the return value so that it is in [0.0, 2 * pi).

Definition at line 313 of file tgUtil.h.

static std::string tgUtil::degSymbol ( )

inlinestatic

Return a degree symbol

Returns: the unicode 'degrees' character

Definition at line 63 of file tgUtil.h.

Here is the caller graph for this function:

static btVector3 tgUtil::getArbitraryNonParallelVector ( btVector3 v )

inlinestatic

Return a random btVector3 that is not parallel to v.

Parameters

[in] v a btVector3, passed by value

Returns: a random btVector3 that is not parallel to v

Definition at line 239 of file tgUtil.h.

Here is the caller graph for this function:

static btQuaternion tgUtil::getQuaternionBetween	(	btVector3	a,
		btVector3	b
	)

inlinestatic

Return a quaternion that, if applied, would rotate vector a to align with vector b.

Parameters

[in]	a	a btVector3, passed by value
[in]	b	a btVector3, passed by value

Returns: a quaternion that, if applied, would rotate vector a to align with vector b

Todo:: get some sensible value if a or b = (0, 0, 0). See getTransform

Definition at line 196 of file tgUtil.h.

Here is the call graph for this function:

static btVector3 tgUtil::getRadiusVector	(	btVector3	axis,
		double	radius,
		btVector3	target
	)

inlinestatic

Return a vector that points to the closest point on the edge of a cylinder when it is added to a vector pointing to the top of the cylinder.

—> = returned vector, if the target is in this direction ^ | | | <- cylinder edge | <- cylinder center

Parameters

[in]	axis	a btVector3, passed by value
[in]	radius	unused
[in]	traget	a btVector3, passed by value

Returns: a vector that points to the closest point on the edge of a cylinder when it is added to a vector pointing to the top of the cylinder

Note: This has not yet been tested as of 05/14/2013

Definition at line 157 of file tgUtil.h.

static btTransform tgUtil::getTransform	(	const btVector3 &	startOrientation,
		const btVector3 &	start,
		const btVector3 &	end
	)

inlinestatic

Return the transform required to place a 'long' element (e.g., a cylinder), rotating from startOrientation, with center of mass between start and end.

Parameters

[in]	start	a btVector3
[in]	end	a btVector3

Returns: the transform required to place a 'long' element (e.g., a cylinder), rotating from startOrientation, with center of mass between start and end

Definition at line 90 of file tgUtil.h.

static btTransform tgUtil::getTransform	(	const btVector3 &	start,
		const btVector3 &	end
	)

inlinestatic

Get a transform using 'up()' as the starting orientation.

Parameters

[in]	start	a btVector3
[in]	end	a btVector3

Definition at line 112 of file tgUtil.h.

Here is the call graph for this function:

static btVector3 tgUtil::getVector	(	const btVector3 &	from,
		const btVector3 &	to
	)

inlinestatic

Get a vector that points from a to b.

Parameters

[in]	from	a btVector3
[in]	to	a btVector3

Returns: the vector difference to - fromn

Definition at line 133 of file tgUtil.h.

Here is the caller graph for this function:

static double tgUtil::rad2deg ( double radians )

inlinestatic

Todo:: write a function that returns the normal of a vector without overwriting the original vector line btVector3's .normalize() functions

Convert radians to degrees.

Parameters

[in] radians an angle measured in radians

Returns: the angle as measured in degrees

Todo:: Normalize the return value so that it is in [0.0, 360.0).

Definition at line 302 of file tgUtil.h.

static std::string tgUtil::strDeg ( double degrees )

inlinestatic

Return a string representation of the given number of degees with the degree symbol appended.

Parameters

[in] degrees a measure in degrees

Returns: a string representation of the given number of degees with the degree symbol appended

Definition at line 325 of file tgUtil.h.

Here is the call graph for this function:

static btVector3 tgUtil::upVector ( )

inlinestatic

Get an 'up' vector (y axis is up)

Returns: a btVector3 (0,1,0)

Definition at line 54 of file tgUtil.h.

Here is the caller graph for this function:

The documentation for this class was generated from the following file:

tgcreator/tgUtil.h
